PRODUCTS / Dough Processing Group / Hydraulic Dough Divider (square divider)
Hydraulic Dough Divider (square divider) Porlanmaz
Hydraulic Dough Divider (square divider) Porlanmaz
0
Hydraulic Dough Divider (square divider) Porlanmaz
1
Hydraulic Dough Divider (square divider) Porlanmaz
2
Hydraulic Dough Divider (square divider) Porlanmaz
3

Machine suitable to divide dough used in bakeries and pastry workshops.Noiseless and reliable hydraulic unit. High quality painted structure and stainless steel version available. Reduced dimensions. Basket and knives in stainless steel. Button for the cleaning of the knives. Usable as a press. Dough up to 70/80% water.

Working cycle in semi-automatic models: pressing and cutting by a joystick, manual lid opening and closing.

Working cycle in automatic models: pressing time adjustable by PLC, automatic pressing, cutting and lid opening.

Model Unit PMHD 10
PMHD 10A
PMHD 20
PMHD 20A
PMHD 24
PMHD 24A
PMHD 30
PMHD 30A
PMHD 1020
PMHD 1020A
PMHD 1530
PMHD 1530A
Operation   Semi-automatic or full automatic
Number of division pcs 10 20 24 30 10/20 15/30
Dividing range g 300-2000 150-1000 120-820 90-650 150-1600 90-1050
Capacity pcs / h 900 1800 2100 2700 900 (10)
1800 (20)
1350 (15)
2700 (30)
Hopper capacity kg 20 20 20 20 16 16
Hopper depth mm 120 120 120 120 120 120
Dividing sizes mm 200x100 100x100 100x80 80x80 100x100 (10)
200x100 (20)
80x80 (15)
163x80 (30)
Width (W) mm 600 600 600 600 600 600
Length (L) mm 700 700 700 700 700 700
Height (H) mm 1120 1120 1120 1120 1120 1120
Height (H1) mm 1635 1635 1635 1635 1635 1635
Electrical power kW 0,75 0,75 0,75 0,75 0,75 0,75
Weight kg 240 240 240 240 240 240
Manufacturer reserves the right to change specifications without prior notice.
